通达信:天途主图源码

HHV(H,20),COLORFF9090,LINETHICK2;
LLV(L,20),COLORFF8080,LINETHICK2;
TR1 := SUM(MAX(MAX(HIGH-LOW,ABS(HIGH-REF(CLOSE,1))),ABS(LOW-REF(CLOSE,1))),14);
HD := HIGH-REF(HIGH,1);
LD := REF(LOW,1)-LOW;
PDM:= SUM(IF(HD>0 AND HD>LD,HD,0),14);
MDM:= SUM(IF(LD>0 AND LD>HD,LD,0),14);
PDI:= PDM*100/TR1;
MDI:= MDM*100/TR1;
A1:=BARSLAST(REF(CROSS("MACD.DIF"(12,26,9),"MACD.DEA"(12,26,9)),1));
B1:=REF(C,A1+1)>C && REF("MACD.DIF"(12,26,9),A1+1)<"MACD.DIF"(12,26,9) && CROSS("MACD.DIF"(12,26,9),"MACD.DEA"(12,26,9));
A2:=BARSLAST(REF(CROSS("KDJ.K"(9,3,3),"KDJ.D"(9,3,3)),1));
B2:=REF(C,A2+1)>C AND REF("KDJ.K"(9,3,3),A2+1)<"KDJ.K"(9,3,3) AND CROSS("KDJ.K"(9,3,3),"KDJ.D"(9,3,3));
A3:=BARSLAST(REF(CROSS("RSI.RSI1"(6,12,24),"RSI.RSI2"(6,12,24)),1));
B3:=REF(C,A3+1)>C AND REF("RSI.RSI1"(6,12,24),A3+1)<"RSI.RSI1"(6,12,24) AND CROSS("RSI.RSI1"(6,12,24),"RSI.RSI2"(6,12,24));
C1:=BARSLAST(REF(CROSS("MACD.DEA"(12,26,9),"MACD.DIF"(12,26,9)),1));
D1:=REF(C,C1+1)<C AND REF("MACD.DIF"(12,26,9),C1+1)>"MACD.DIF"(12,26,9) AND CROSS("MACD.DEA"(12,26,9),"MACD.DIF"(12,26,9));
C2:=BARSLAST(REF(CROSS("KDJ.D"(9,3,3),"KDJ.K"(9,3,3)),1));
D2:=REF(C,C2+1)<C AND REF("KDJ.K"(9,3,3),C2+1)>"KDJ.K"(9,3,3) AND CROSS("KDJ.D"(9,3,3),"KDJ.K"(9,3,3));
C3:=BARSLAST(REF(CROSS("RSI.RSI2"(6,12,24),"RSI.RSI1"(6,12,24)),1));
D3:=REF(C,C3+1)<C AND REF("RSI.RSI1"(6,12,24),C3+1)>"RSI.RSI1"(6,12,24) AND CROSS("RSI.RSI2"(6,12,24),"RSI.RSI1"(6,12,24));
C4:=BARSLAST(REF(CROSS(MDI,PDI),1));
D4:=REF(C,C4+1)<C AND REF(MDI,C4+1)>MDI AND CROSS(MDI,PDI);
A4:=BARSLAST(REF(CROSS(PDI,MDI),1));
B4:=REF(C,A4+1)>C AND REF(PDI,A4+1)<PDI AND CROSS(PDI,MDI);
{下面是文字显示各种背离}
DRAWTEXT(B4,L-0.09,'DMI底背'),COLORFFCCFF;
DRAWTEXT(D4,H+0.09,'DMI顶背'),COLORWHITE;
DRAWTEXT(B1,L-0.09,'MACD底背'),COLORFF00FF;
DRAWTEXT(B2,L-0.09,'KDJ底背'),COLORYELLOW;
DRAWTEXT(B3,L-0.09,'RSI底背'),COLORRED;
DRAWTEXT(D1,H+0.09,'MACD顶背'),COLORFFCC66;
DRAWTEXT(D2,H+0.09,'KDJ顶背'),COLORC0A8FF;
DRAWTEXT(D3,H+0.09,'RSI顶背'),COLORFFCCCC;
VLL:=CROSS(MA(C,13),MA(C,21));
DRAWTEXT(VLL,MA(C,13)-0.09,'圆弧底'),COLORWHITE;
MA13:=MA(C,13);
{,COLORRED,LINETHICK2;}
IF(MA13>=REF(MA13,1),MA13,DRAWNULL),COLORRED,LINETHICK2;
IF(MA13<REF(MA13,1),MA13,DRAWNULL),COLORGREEN,LINETHICK2;
{下面是立体K线柱线，16限制，挑肥拣瘦关闭一部分}
{STICKLINE(C>=O,C,O,7,0),COLORRED;
STICKLINE(C<=O,C,O,7,0),COLORFF2020;
STICKLINE(C>=O,C,O,4,0),COLOR7070FF;
STICKLINE(C<=O,C,O,4,0),COLORFF6600;}
STICKLINE(C>=O,C,O,2,0),COLORYELLOW;{
STICKLINE(C<=O,C,O,2,0),COLORFFCC66;}
STICKLINE(C>=O,H,L,0,0),COLORYELLOW;
STICKLINE(C<=O,H,L,0,0),COLORFFCC66;
{下面是显示各种背离柱线，16根线限制，全关闭}
{STICKLINE(B4,L,L-0.06,4,0),COLORFFCCFF;//DMI底背
STICKLINE(D4,H,H+0.06,4,0),COLORWHITE;//DMI顶背
STICKLINE(B1,L,L-0.06,4,0),COLORFF00FF;//MACD底背
STICKLINE(B2,L,L-0.06,4,0),COLORYELLOW;//KDJ底背
STICKLINE(B3,L,L-0.04,4,0),COLORRED;//RSI底背
STICKLINE(D1,H,H+0.06,4,0),COLORFFCC66;//MACD顶背
STICKLINE(D2,H,H+0.06,4,0),COLORC0A8FF;//KDJ顶背
STICKLINE(D3,H,H+0.06,4,0),COLORFFCCCC;//RSI顶背
DRAWTEXT(VLL,MA(C,13),'●'),COLORWHITE;//圆弧底};
