通达信支撑压力画线主图源码

A1:=REF(HIGH,3)=HHV(HIGH,2*3+1); B1:=FILTER(A1,3); C1:=BACKSET(B1,3+1); D1:=FILTER(C1,3);{高点}
A2:=REF(LOW,3)=LLV(LOW,2*3+1); B2:=FILTER(A2,3); C2:=BACKSET(B2,3+1); D2:=FILTER(C2,3);{低点}
E1:=(REF(LLV(LOW,2*3),1)+REF(HHV(HIGH,2*3),1))/2; E2:=(HIGH+LOW)/2;{高低点出现在同一K线上可作取舍}
H1:=(D1 AND NOT(D2 AND E1>=E2)) OR ISLASTBAR OR BARSCOUNT(CLOSE)=1;
 L1:=(D2 AND NOT(D1 AND E1<E2)); H2:=D1 AND NOT(D2 AND E1>=E2);
 X1:=REF(BARSLAST(H1),1)+1; F1:=BACKSET(H1 AND COUNT(L1,X1)>0,LLVBARS(IF(L1,LOW,10000),X1));
 G1:=F1>REF(F1,1); I1:=BACKSET(G1,2); LD:=I1>REF(I1,1);{过滤后低点}
L2:=LD OR ISLASTBAR OR BARSCOUNT(CLOSE)=1;
 X2:=REF(BARSLAST(L2),1)+1; F2:=BACKSET(L2 AND COUNT(H2,X2)>0,HHVBARS(IF(H2,HIGH,0),X2));
 G2:=F2>REF(F2,1); I2:=BACKSET(G2,2); HD:=I2>REF(I2,1);{过滤后高点}
DRAWLINE(LD,L,HD,H,0),COLORWHITE,LINETHICK1,DOTLINE;
 DRAWLINE(HD,H,LD,L,0),COLORWHITE,LINETHICK1,DOTLINE;
 J1:=BACKSET(ISLASTBAR,MIN(BARSLAST(HD),BARSLAST(LD))+1); J2:=J1>REF(J1,1);
 DRAWLINE(J2,IF(HD,H,L),ISLASTBAR,IF(BARSLAST(HD)>BARSLAST(LD),H,L),0),COLORWHITE,LINETHICK1,DOTLINE;
 A3:=H<REF(H,REF(BARSLAST(HD),1)+1);
 B3:=REF(H,REF(BARSLAST(HD),1)+1)>REF(H,REF(BARSLAST(HD),1)+2+REF(BARSLAST(HD),REF(BARSLAST(HD),1)+2));
 D3:=A3 AND B3 AND HD; E3:=BACKSET(D3,REF(BARSLAST(HD),1)+2);
 HH:=E3>REF(E3,1);{找出全部?期高?}
A4:=L>REF(L,REF(BARSLAST(LD),1)+1);
 B4:=REF(L,REF(BARSLAST(LD),1)+1)<REF(L,REF(BARSLAST(LD),1)+2+REF(BARSLAST(LD),REF(BARSLAST(LD),1)+2));
 D4:=A4 AND B4 AND LD; E4:=BACKSET(D4,REF(BARSLAST(LD),1)+2); LL:=E4>REF(E4,1);{找出全部?期低?}
DRAWICON(HH,H,10); DRAWICON(LL,L,12);
 H3:=HH OR ISLASTBAR OR BARSCOUNT(C)=1; {后面?行，方法同前。只是不用考?高低?出?在同一K?}
 X3:=REF(BARSLAST(H3),1)+1; F3:=BACKSET(H3 AND COUNT(LL,X3)>0,LLVBARS(IF(LL,L,POW(10,20)),X3));
 G3:=F3>REF(F3,1); I3:=BACKSET(G3,2); LZ:=I3>REF(I3,1); {?期低?，也可供引用}
L4:=LZ OR ISLASTBAR OR BARSCOUNT(C)=1;
 X4:=REF(BARSLAST(L4),1)+1; F4:=BACKSET(L4 AND COUNT(HH,X4)>0,HHVBARS(IF(HH,H,-POW(10,20)),X4));
 G4:=F4>REF(F4,1); I4:=BACKSET(G4,2); HZ:=I4>REF(I4,1);{?期高?，也可供引用}
DRAWLINE(HZ,H,LZ,L,0),COLORGREEN,LINETHICK1;
 DRAWLINE(LZ,L,HZ,H,0),COLORGREEN,LINETHICK1;{?期}
K1:=BACKSET(ISLASTBAR,MIN(BARSLAST(HZ),BARSLAST(LZ))+1); K2:=K1>REF(K1,1);
 DRAWLINE(K2,IF(HZ,H,L),ISLASTBAR,C,0),COLORGREEN,LINETHICK1; {最后的?期，?在收?价上}
UU:=BACKSET(ISLASTBAR,BARSLAST(LD)+1);
 VV:=UU>REF(UU,1);
 WW:=BACKSET(VV,REF(BARSLAST(LD),1)+2);
 XX:=WW>REF(WW,1);
 DRAWLINE(XX,L,VV,L,1),COLORMAGENTA,LINETHICK1;
 UU2:=BACKSET(ISLASTBAR,BARSLAST(HD)+1);
 VV2:=UU2>REF(UU2,1);
 WW2:=BACKSET(VV2,REF(BARSLAST(HD),1)+2);
 XX2:=WW2>REF(WW2,1);
 DRAWLINE(XX2,H,VV2,H,1),COLORMAGENTA,LINETHICK1;
 DRAWNUMBER(LD,L*0.999,L),COLORWHITE;
 DRAWNUMBER(HD,H*1.002,H),COLORWHITE;
 AA:=BARSLAST(HD);
 BB:=BARSLAST(LD);
 DRAWNUMBER(LD,L*0.992,AA),COLORGREEN;
 DRAWNUMBER(HD,H*1.013,BB),COLORRED;
 DRAWTEXT(LD,L*0.988,'         天'),COLORGREEN;
 DRAWTEXT(HD,H*1.01,'         天'),COLORRED;
 DRAWNUMBER(ISLASTBAR,L*0.989,MIN(AA,BB)),COLORCYAN;
 DRAWTEXT(ISLASTBAR,L*0.987,'           天'),COLORCYAN;
 STICKLINE(LD,1.015*H,0.98*L,0,-1),COLORYELLOW;
 {VERTLINE(LD),POINTDOT;
 VVV:REF(SUM(V,SUMBARS(LD=1,2)),BARSLAST(LD=1)),LINETHICK0;};
